筒管規格
Bobbin spec | 6"(170mm) |
| 結構
Layout | 雙面機，每臺（12-96）錠
Double-sided, one-machine has （12-96） spindles |
| 電源
Power Supply | 三相380V 50/60HZ/Three phases 380V 50/60HZ |
| 驅動
Transmission | 單錠獨立直流馬達驅動
Every spindle is driven by a AC motor individually |
| 消耗功率
Power Comsumption | 0.09千瓦/錠/0.09KW/spindle |
| 成型筒子
Take-up package | 圓形柱(0°)/Cylinrical (0°)錐形；4°20, 5°57, 9°15 cone |
| 筒子直徑
Package Diameter | 最大200和290毫米／Max．200and 290mm |
| 紗線速度范圍
Yam speed | 300-1000m/min |
| 電子防重疊裝置
Electrical wobble frequency anti-patterning function | 變頻器控制／Control by the lnverter |
| 定長裝置
Length counting device | 可編程控制器（PLC）集中控制/顯示計長
Controlled and displayed by PLC |
| 張力器
Yarn tension and waxer adjusting device | 每錠配置旋轉自清潔張力器和上臘
Every spindle has a self-cleaning yarn tension and waxer adjusting device |
| 機械清紗裝置
Slub-Catcher | 每錠配置可微調機械清紗刀
Every spindle has a Mechanical Slub-Catcher |
| 斷紗自停裝置
Yarn break control device | 電子斷紗自停
The spindle will stop when the yarn breaks by a yambreak control device |
| 調速裝置
Speed Regulation | 變頻調速/By inverter |
| 筒紗軟邊橫動裝置
Anti-hard edge device | 機械式/Mechanically/適合松式/suitable soft winder |
| 電子式清紗裝置
Electronic Slub-Catcher | 可選配/Ordered separately |
| 空氣捻接器
Splicer | 可選配/Ordered separately |
| 吹吸風清潔器
Blows the inflow cleaner | 可選配/Ordered separately |
| 照明系統（帶燈）
Lighting system | 可選配/Ordered separately |
| 外形尺寸（毫米）
Dimensions | 13700(長/length)×1050(寬/width)×1650(高/height)mm |
